D1G – D7G
Document number: DS29001 Rev. 4 - 2
1 of 3
www.diodes.com
January 2012
© Diodes Incorporated
D1G - D7G
1.0A GLASS PASSIVATED RECTIFIER
Features and Benefits
•
Glass Passivated Die Construction
• High Current Capability and Low Forward Voltage Drop
• Surge Overload Rating to 30A Peak
•
Lead Free Finish, RoHS Compliant (Note 1)
Mechanical Data
• Case:
T1
• Case Material: Molded Plastic. UL Flammability
• Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Polarity: Cathode Band
• Terminals: Finish – Tin. Solderable per MIL-STD-202, Method 208
• Marking: Type Number
•
Weight: 0.13 grams (approximate)
Ordering Information
(Note 2)
Device Packaging Shipping
D1G-T T-1 5K/Tape & Reel, 13-inch
D2G-T T-1 5K/Tape & Reel, 13-inch
D3G-T T-1 5K/Tape & Reel, 13-inch
D4G-T T-1 5K/Tape & Reel, 13-inch
D5G-T T-1 5K/Tape & Reel, 13-inch
D6G-T T-1 5K/Tape & Reel, 13-inch
D7G-T T-1 5K/Tape & Reel, 13-inch
Maximum Ratings and Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic Symbol D1G D2G D3G D4G D5G D6G D7G Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V
RRM
V
RWM
V
R
50 100 200 400 600 800 1000 V
RMS Reverse Voltage V
R(RMS)
35 70 140 280 420 560 700 V
Average Rectified Output Current
(Note
3) @ T
A
= 75
°C I
O
1.0 A
Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave superimposed on rated load
I
FSM
30 A
Forward Voltage @ I
F
= 1.0A V
FM
1.0 V
Peak Reverse Current @ T A = 25
°C
at Rated DC Blocking Voltage @ T A = 100
°C
I RM
5.0
50
μA
Typical Reverse Recovery Time (Note 4) t
rr
2.0 μs
Typical Total Capacitance (Note 5) C
T
8.0 pF
Typical Thermal Resistance Junction to Ambient R θJA 100 °C/W
Operating and Storage Temperature Range T
J ,
T
STG
-65 to +150 °C
Notes: 1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied, see EU Directive 2002/95/EC Annex Notes
2. For packaging details, visit our website at http://www.diodes.com.
3. Valid provided that leads are maintained at ambient temperature at a distance of 9.5mm from the case.
4. Measured with I
F
= 0.5A, I
R
= 1A, I
rr
= 0.25A.
5. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
