Diodes 10A01 - 10A07 User Manual
10a rectifier features, Maximum ratings and electrical characteristics, Mechanical data

e
3
DS28010 Rev. 4 - 2
1 of 3
10A01-10A07
www.diodes.com
ã
Diodes Incorporated
10A01 - 10A07
10A RECTIFIER
Features
A
A
B
C
D
R-6
Dim
Min
Max
A
25.40
—
B
8.60
9.10
C
1.20
1.30
D
8.60
9.10
All Dimensions in mm
Maximum Ratings and Electrical Characteristics
@ T
A
= 25°C unless otherwise specified
·
High Current Capability and Low Forward Voltage Drop
·
Surge Overload Rating to 600A Peak
·
Low Reverse Leakage Current
·
Lead Free Finish, RoHS Compliant (Note 3)
Mechanical Data
·
Case: R-6
·
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
·
Moisture Sensitivity: Level 1 per J-STD-020C
·
Terminals: Finish
¾ Tin. Plated Leads Solderable per
MIL-STD-202, Method 208
·
Polarity: Cathode Band
·
Ordering Information: See Last Page
·
Marking: Type Number
·
Weight: 2.1 grams (approximate)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic
Symbol
10A01
10A02
10A03
10A04
10A05
10A06
10A07
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
50
100
200
400
600
800
1000
V
RMS Reverse Voltage
V
R(RMS)
35
70
140
280
420
560
700
V
Average Rectified Output Current
(Note 1)
@ T
A
= 50°C
I
O
10
A
Non-Repetitive Peak Forward Surge Current 8.3ms
single half sine-wave superimposed on rated load
I
FSM
600
A
Forward Voltage
@ I
F
= 10A
V
FM
1.0
V
10Peak Reverse Current
@T
A
= 25°C
at Rated DC Blocking Voltage
@ T
A
= 100°C
I
RM
10
100
µA
Typical Total Capacitance (Note 2)
C
T
150
80
pF
Typical Thermal Resistance Junction to Ambient
R
qJA
10
°C/W
Operating and Storage Temperature Range
T
j,
T
STG
-65 to +150
°C
Notes: 1. Leads maintained at ambient temperature at a distance of 9.5mm from the case.
2. Measured at 1.0 MHz and applied reverse voltage of 4.0V DC.
3. RoHS revision 13.2.2003. Glass and High Temperature Solder Exemptions Applied, see
