B3L30LP
Document number: DS30915 Rev. 11 - 2
2 of 5
March 2014
© Diodes Incorporated
B3L30LP
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
30 V
RMS Reverse Voltage
V
R(RMS)
21 V
Average Rectified Output Current
I
O
3.0 A
Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave Superimposed on Rated Load
I
FSM
30 A
Thermal Characteristics
Characteristic Symbol
Typ
Max
Unit
Thermal Resistance Junction to Soldering Point
R
θJS
⎯
3
°C/W
Thermal Resistance Junction to Ambient Air
(Note 5)
R
θJA
130
⎯
°C/W
Power Dissipation
(Note 6)
(Note 7)
(Note 8)
P
D
⎯
⎯
⎯
2.5
4.0
4.5
W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Reverse Breakdown Voltage (Note 9)
V
(BR)R
30
⎯
⎯
V
I
R
= 5.0mA
Forward Voltage
V
F
⎯
0.28
⎯
V
I
F
= 0.5A, T
J
= +25°C
⎯
0.30 0.35
I
F
= 1.0A, T
J
= +25°C
⎯
0.18 0.29
I
F
= 1.0A, T
J
= +125°C
⎯
0.33 0.40
I
F
= 2.0A, T
J
= +25°C
⎯
0.22 0.37
I
F
= 2.0A, T
J
= +125°C
⎯
0.35
0.45
I
F
= 3.0A, T
J
= +25°C
⎯
0.26 0.42
I
F
= 3.0A, T
J
= +125°C
Reverse Current (Note 9)
I
R
⎯
0.27 1.0 mA
T
J
= +25°C, V
R
= 30V
⎯
55 90 mA
T
J
= +100°C, V
R
= 30V
Notes:
5. FR-4 PCB, 2 oz. Copper, minimum recommended pad lay T
A
= +25°C.
6. Device mounted on FR-4 PCB, 25mm
2
pad area.
7. Device mounted on FR-4 PCB, 75mm
2
pad area.
8. Aluminum PCB with copper mounting pad area of 75mm
2
.
9. Short duration pulse test used to minimize self-heating effect.
