SCHOTTKY BARRIER RECTIFIERS APD240
Data Sheet
5
Nov. 2012 Rev. 1. 9 BCD Semiconductor Manufacturing Limited
Figure 5. Maximum Non-Repetitive Figure 6. Typical Reverse Characteristics
Figure 7. Typical Junction Capacitance
Typical Performance Characteristics (Continued)
Peak Forward Surge Current
1 10 100
10
15
20
25
30
35
40
45
50
Peak Forward Surge
Current (A)
Number of Cycles at 60Hz
T
J
=T
J
max
Single Half Sine-Wave
0 20 40 60 80 100
1
10
100
1000
10000
100000
In
stantanous R
evers
e
Current (
µ
A)
Percent of Rated Peak Reverse Voltage (%)
T
J
=25 o C
T
J
=125 o C
0.1 1 10 100
10
100
Junc
tio
n C
ap
ac
itanc
e
(p
F)
Reverse Voltage (V)
T
J
=25 o C
f=1.0MHz
V
SIG
=50mVp-p
