SCHOTTKY BARRIER RECTIFIERS APD340
Data Sheet
4
Aug. 2011 Rev. 1. 3 BCD Semiconductor Manufacturing Limited
Parameter Symbol Values Unit
Typical Thermal Resistance
θ
JA
DO-27 40
o C/W
DO-214AC 75
Thermal Characteristics (T
A
=25
o
C, unless otherwise noted)
Parameter Symbol Values Unit
Forward Voltage @ I
F
=3.0A V
F
0.5 V
Reverse Current @ Rated V
R
(Note 2)
T
A
=25
o C
I
R
0.5
mA
T
A
=100
o
C
10
Electrical Characteristics (T
A
=25 o C, unless otherwise noted)
Note 2: Pulse Test: 300 µs pulse width, 1.0% duty cycle.
Figure 3. Typical Instantaneous Forward Characteristics Figure 4. Typical Reverse Characteristics
Typical Performance Characteristics
(T
A
=25
o
C, unless otherwise noted)
0 10 20 30 40
1
10
100
1000
10000
Inst
ant
aneous R
everse Current
(
µ
A)
Peak Reverse Voltage (V)
T
J
=25
o
C
T
J
=125
o
C
0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4
0.1
1
10
Instantan
eous
F
o
rw
ard
C
urrent (A
)
Instantaneous Forward Voltage (V)
T
J
=25 o C
T
J
=125 o C
