Data Sheet
SCHOTTKY BARRIER RECTIFIER APD360
Aug. 2011 Rev. 1. 8 BCD Semiconductor Manufacturing Limited
2
Pin Configuration
VP Package VPL Package
(DO-27) (DO-27 (L))
VR Package
(DO-214AC)
Figure 2. Pin Configuration of APD360 (Top View)
Cathode
Anode
Cathode line by
marking
Cathode line by
marking
Cathode
Anode
Cathode line
by marking
Cathode
Anode
