ZR4040-5.0
ZR4040-5.0
Document number: DS32179 Rev. 4 - 2
4 of 5
June 2010
© Diodes Incorporated
A Product Line of
Diodes Incorporated
Ordering Information*
Order
Reference
Tol
(%)
Package
Device
Mark
Status (*)
Reel Size
(inches)
Quantity
per reel
Tape Width
(mm)
ZR40401F50TA 1 SOT23
50M
Released
7
3000
8
ZR40402F50TA 2 SOT23
50L
Not Recommended
for New Designs
7 3000 8
Notes:
*All ZR4040R50 variants (E-Line) are obsolete.
Package Outline Dimensions
SOT23
E
e
L
e1
D
A
c
E1
L1
A1
b
3 leads
Dim.
Millimeters Inches
Dim.
Millimeters Inches
Min. Max. Min. Max.
Min. Max. Min. Max.
A
-
1.12
-
0.044
e1
1.90 NOM
0.075 NOM
A1 0.01 0.10
0.0004
0.004 E 2.10 2.64 0.083
0.104
b 0.30 0.50 0.012
0.020 E1 1.20 1.40 0.047
0.055
c 0.085 0.20 0.003 0.008
L
0.25 0.60 0.0098
0.0236
D 2.80 3.04 0.110
0.120 L1 0.45 0.62 0.018
0.024
e 0.95
NOM 0.037
NOM - - - - -
Note: Controlling dimensions are in millimeters. Approximate dimensions are provided in inches
