ZR4040-2.5
ZR4040-2.5
Document number: DS32180 Rev. 5 - 2
4 of 5
June 2010
© Diodes Incorporated
A Product Line of
Diodes Incorporated
Ordering Information
*
Order
Reference
Tol
(%)
Package
Device Mark
Status (*)
Reel Size
(inches)
Quantity
per reel
Tape Width
(mm)
ZR40401F25TA 1
SOT23
25M
Released
7
3000
8
ZR40402F25TA 2
SOT23
25L
Released
7
3000
8
ZR404005F25TA 0.5
SOT23
25V
Released
7
3000
8
Notes:
*All ZR4040R25 variants (E-Line) are obsolete and no longer available for sale. The closest alternative is the SOT23.
Package Outline Dimensions
SOT23
E
e
L
e1
D
A
c
E1
L1
A1
b
3 leads
Dim.
Millimeters Inches
Dim.
Millimeters Inches
Min. Max. Min. Max.
Min. Max. Min. Max.
A
-
1.12
-
0.044
e1
1.90 NOM
0.075 NOM
A1 0.01 0.10
0.0004
0.004 E 2.10 2.64 0.083
0.104
b 0.30 0.50 0.012
0.020 E1 1.20 1.40 0.047
0.055
c 0.085 0.20 0.003 0.008
L
0.25 0.60 0.0098
0.0236
D 2.80 3.04 0.110
0.120 L1 0.45 0.62 0.018
0.024
e 0.95
NOM 0.037
NOM - - - - -
Note: Controlling dimensions are in millimeters. Approximate dimensions are provided in inches
