ZXCT1021
Issue 9 - July 2007 2 www.zetex.com
© Zetex Semiconductors plc 2007
Absolute maximum ratings
Pinout information
Voltage on any pin
with respect to END pin -0.6V to 20V
V
SENSE
-0.6V to V
IN
+0.5V
Operating temperature -40 to 85°C
Storage temperature -55 to 150°C
Package power dissipation (T
amb
= 25°C)
SOT23-5 300mW
Pin name Pin function
N/C Not internally connected
GND Ground
V
OUT
Voltage output referenced to GND. Intended to drive high impedance loads
V
SENSE -
High impedance negative sense voltage input
V
SENSE+
Supply and positive sense voltage input
