ZXMN6A11Z
Document number DS33557 Rev. 4 - 2
1 of 7
December 2011
© Diodes Incorporated
ADVAN
CE I
N
F
O
RM
ATI
O
N
A Product Line of
Diodes Incorporated
ZXMN6A11Z
60V N-CHANNEL ENHANCEMENT MODE MOSFET IN SOT89 PACKAGE
Product Summary
V
(BR)DSS
R
DS(on)
Max
I
D
max
T
A
= 25
°C
(Note 5)
60V
120m
Ω @ V
GS
= 10V
3.6A
180m
Ω @ V
GS
= 4.5V
2.9A
Description and Applications
This MOSFET has been designed to minimize the on-state resistance
(R
DS(on)
) and yet maintain superior switching performance, making it
ideal for high efficiency power management applications.
•
DC-DC Converters
•
Power Management functions
•
Motor control
•
Disconnect switches
Features and Benefits
• Low
On-Resistance
• Low
Threshold
•
Fast Switching Speed
•
Low Gate Drive
•
Lead Free/RoHS Compliant (Note 1)
•
"Green" Device (Note 2)
•
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
• Case:
SOT89
•
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Terminals: Matte Tin Finish
•
Weight: 0.052 grams (approximate)
Ordering Information
(Note 3)
Product
Marking
Reel size (inches)
Tape width (mm)
Quantity per reel
ZXMN6A11ZTA 11N6
7
12
1,000
Notes:
1. No purposefully added lead.
2. Diodes Inc’s “Green” Policy can be found on our websit
3. For packaging details, go to our website at
Marking Information
Top View
SOT89
Device symbol
Top View
Pin-Out
11N6 = Product type Marking Code
D
S
G
11N6
