ZXTD2090DE6
Electrical Characteristics - Q1 & Q2 common
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Collector-Base Breakdown Voltage
BV
CBO
50 V
I
C
= 100µA
Collector-Emitter Breakdown Voltage (Note 12)
BV
CEO
50 V
I
C
= 10mA
Emitter-Base Breakdown Voltage
BV
EBO
7 V
I
E
= 100µA
Collector-Base Cutoff Current
I
CBO
10
nA
V
CB
= 40V
Collector-Emitter Cutoff Current
I
CES
10
nA
V
CES
= 40V
Emitter Cutoff Current
I
EBO
10
nA
V
EB
= 5.6V
DC Current Gain (Note 12)
h
FE
200
300
200
75
20
420
450
350
130
60
I
C
= 10mA, V
CE
= 2V
I
C
= 100mA, V
CE
= 2V
I
C
= 500mA, V
CE
= 2V
I
C
= 1A, V
CE
= 2V
I
C
= 1.5A, V
CE
= 2V
Collector-Emitter Saturation Voltage (Note 12)
V
CE(sat)
24
60
120
160
35
80
200
270
mV
I
C
= 100mA, I
B
= 10mA
I
C
= 250mA, I
B
= 10mA
I
C
= 500mA, I
B
= 10mA
I
C
= 1A, I
B
= 50mA
Base-Emitter Saturation Voltage (Note 12)
V
BE(sat)
940
1100
mV
I
C
= 1A, I
B
= 50mA
Base-Emitter Turn-On Voltage (Note 12)
V
BE(on)
850
1100
mV
I
C
= 1A, V
CE
= 2V
Output Capacitance
C
obo
10 pF
V
CB
= 10V. f = 1MHz
Current Gain-Bandwidth Product
f
T
215 MHz
V
CE
= 10V, I
C
= 50mA
f = 100MHz
Turn-On Time
t
on
150 ns
V
CC
= 10V, I
C
= 1A
I
B1
= I
B2
= 100mA
Turn-Off Time
t
off
425 ns
Note:
12. Measured under pulsed conditions. Pulse width ≤ 300 µs. Duty cycle ≤ 2%
