ZXTN25020DZ
20V NPN high gain transistor in SOT89
Summary
BV
CEX
> 100V
BV
CEO
> 20V
BV
ECX
> 6V
I
C(cont)
= 6A
V
CE(sat)
< 48mV @ 1A
R
CE(sat)
= 30m
⍀
P
D
= 2.4W
Complementary part number ZXTP25020DZ
Description
Packaged in the SOT89 outline this new low saturation 20V NPN
transistor offers extremely low on state losses making it ideal for use in
DC-DC circuits and various driving and power management functions
Features
•
6 Amps continuous current
•
Up to 15 Amps peak current
•
High current gain
•
Very low saturation voltages
•
100V forward blocking voltage
•
6V reverse blocking voltage
Applications
•
Emergency lighting circuits
•
Motor driving
•
Camera strobe
•
Boost converters
•
Backlight inverters
•
MOSFET gate drivers
•
LED Driving
Ordering information
Device marking
1K8
Device
Reel size
(inches)
Tape width
(mm)
Quantity
per reel
ZXTN25020DZTA
7
12
1000
C
E
B
C
E
Pinout - top view
C
B
