ZXTN25012EZ
12V NPN high gain transistor in SOT89
Summary
BV
CEO
> 12V
BV
ECX
> 6V
h
FE
> 500
I
C(cont)
= 6.5A
V
CE(sat)
< 38mV @ 1A
R
CE(sat)
= 25m
⍀
P
D
= 2.4W
Complementary part number ZXTP25012EZ
Description
Packaged in the SOT89 outline this new ultra high gain, low saturation
12V NPN transistor offers extremely low on state losses making it ideal
for use in DC-DC circuits and various driving and power management
functions
Features
•
6.5A continuous current
•
Up to 15A peak current
•
Very low saturation voltages
•
6V reverse blocking voltage
Applications
•
LED driving
•
Motor driving
•
Boost converters
•
Royer converters
•
Camera strobe
•
MOSFET gate drivers
Ordering information
Device marking
1K7
Device
Reel size
(inches)
Tape width
(mm)
Quantity
per reel
ZXTN25012EZTA
7
12
1000
C
E
B
C
E
Pinout - top view
C
B
