ZXTD618MC

Document Number DS31931 Rev. 2 - 2

4 of 7

www.diodes.com

January 2011

© Diodes Incorporated

A Product Line of

Diodes Incorporated

ZXTD618MC







Electrical Characteristics

@T

A

= 25°C unless otherwise specified

Characteristic Symbol

Min

Typ

Max

Unit

Test

Condition

Collector-Base Breakdown Voltage

BV

CBO

40 100 -

V I

C

= 100µA

Collector-Emitter Breakdown Voltage (Note 10)

BV

CEO

20 27 -

V

I

C

= 10mA

Emitter-Base Breakdown Voltage

BV

EBO

7.0 8.2 -

V I

E

= 100µA

Collector Cutoff Current

I

CBO

- -

100

nA

V

CB

= 30V

Emitter Cutoff Current

I

EBO

- -

100

nA

V

EB

= 6V

Collector Emitter Cutoff Current

I

CES

- -

100

nA

V

CES

= 16V

Static Forward Current Transfer Ratio (Note 10)

h

FE

200
300
200
100

400
450
360
180

-
-
-
-

-

I

C

= 10mA, V

CE

= 2V

I

C

= 200mA, V

CE

= 2V

I

C

= 2A, V

CE

= 2V

I

C

= 6A, V

CE

= 2V

Collector-Emitter Saturation Voltage (Note 10)

V

CE(sat)

-
-
-
-
-

8

90

115
190
210

15

150
135
250
300

mV

I

C

= 0.1A, I

B

= 10mA

I

C

= 1A, I

B

= 10mA

I

C

= 2A, I

B

= 50mA

I

C

= 3A, I

B

= 100mA

I

C

= 4.5A, I

B

= 125mA

Base-Emitter Turn-On Voltage (Note 10)

V

BE(on)

- 0.88

0.97 V

I

C

= 4.5A, V

CE

= 2V

Base-Emitter Saturation Voltage (Note 10)

V

BE(sat)

- 0.98

1.07 V

I

C

= 4.5A, I

B

= 125mA

Output Capacitance

C

obo

- 23 30 pF

V

CB

= 10V. f = 1MHz

Transition Frequency

f

T

100 140 -

MHz

V

CE

= 10V, I

C

= 50mA,

f = 100MHz

Turn-on Time

t

on

- 170 - ns

V

CC

= 10V, I

C

= 3A

I

B1

= I

B2

= 10mA

Turn-off Time

t

off

- 400 - ns

Notes: 10. Measured under pulsed conditions. Pulse width

≤ 300 µs. Duty cycle ≤ 2%
