ZXTD617MC
Document Number DS31930 Rev. 3 - 2
4 of 7
December 2010
© Diodes Incorporated
A Product Line of
Diodes Incorporated
ZXTD617MC
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Collector-Base Breakdown Voltage
BV
CBO
40 70 -
V
I
C
= 100µA
Collector-Emitter Breakdown Voltage (Note 9)
BV
CEO
15 18 -
V
I
C
= 10mA
Emitter-Base Breakdown Voltage
BV
EBO
7 8.2 -
V
I
E
= 100µA
Collector Cutoff Current
I
CBO
- -
100
nA
V
CB
= 30V
Emitter Cutoff Current
I
EBO
- -
100
nA
V
EB
= 6V
Collector Emitter Cutoff Current
I
CES
- -
100
nA
V
CES
= 12V
Static Forward Current Transfer Ratio (Note 9)
h
FE
200
300
200
150
-
415
450
320
240
80
-
-
-
-
-
-
-
-
-
-
I
C
= 10mA, V
CE
= 2V
I
C
= 200mA, V
CE
= 2V
I
C
= 3A, V
CE
= 2V
I
C
= 5A, V
CE
= 2V
I
C
= 12A, V
CE
= 2V
Collector-Emitter Saturation Voltage (Note 9)
V
CE(sat)
-
-
-
-
-
8
70
165
240
200
14
100
200
310
-
mV
mV
mV
mV
mV
I
C
=0.1A, I
B
= 10mA
I
C
= 1A, I
B
= 10mA
I
C
= 3A, I
B
= 50mA
I
C
=4.5A, I
B
= 50mA
I
C
=4.5A, I
B
= 100mA
Base-Emitter Turn-On Voltage (Note 9)
V
BE(on)
- 0.88
0.96 V
I
C
= 4.5A, V
CE
= 2V
Base-Emitter Saturation Voltage (Note 9)
V
BE(sat)
- 0.94
1.05 V
I
C
= 4.5A, I
B
= 50mA
Output Capacitance
C
obo
- 30 40 pF
V
CB
= 10V. f = 1MHz
Transition Frequency
f
T
80 120 - MHz
V
CE
= 10V, I
C
= 50mA,
f = 100MHz
Turn-on Time
t
on
- 120 - ns
V
CC
= 10V, I
C
= 1A
I
B1
= I
B2
= 10mA
Turn-off Time
t
off
- 160 - ns
Notes: 9. Measured under pulsed conditions. Pulse width
≤ 300 µs. Duty cycle ≤ 2%
