ZXT10P20DE6
A Product Line of
Diodes Incorporated
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Collector-Base Voltage V
CBO
-20 V
Collector-Emitter Voltage V CEO
-20 V
Emitter-Base Voltage V
EBO
-7 V
Base Current I
B
-500 mA
Continuous Collector Current I
C
-2.5 A
Peak Pulse Collector Current I
CM
-6 A
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation
Linear Derating Factor
(Note 5)
P D
1.1
8.8
W
mW/°C
(Note 6)
1.7
13.6
Thermal Resistance, Junction to Ambient
(Note 5)
R θJA
113
°C/W
(Note 6) 73
Thermal Resistance, Junction to Leads (Note 7) R θJL 30.01 °C/W

Operating and Storage Temperature Range T
J
, T
STG
-55 to +150 °C
ESD Ratings
(Note 8)
Characteristic Symbol Value Unit JEDEC Class
Electrostatic Discharge - Human Body Model ESD HBM 4,000 V 3A
Electrostatic Discharge - Machine Model ESD MM 400 V C
Notes: 5. For a device mounted with collector leads on 25mm x 25mm 1oz copper that is on a single-sided 1.6mm FR4 PCB; device is measured under still air
conditions whilst operating in a steady-state.
6. Same as note (5), except the device is measured at t  5secs.
7. Thermal resistance from junction to solder-point (at the end of the collector leads).
8. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
