NPN TRANSISTOR
ELECTRICAL CHARACTERISTICS (at T
amb
= 25°C).
PARAMETER SYMBOL MIN. TYP. MAX. UNIT CONDITIONS.
Collector-Base
Breakdown Voltage
V
(BR)CBO
20 100 V I
C
=100 µ A
Collector-Emitter
Breakdown Voltage
V
(BR)CEO
20 27 V I
C
=10mA*
Emitter-Base
Breakdown Voltage
V
(BR)EBO
5 8.3 V I
E
=100 µ A
Collector Cutoff
Current
I
CBO
100 nA V
CB
=16V
Emitter Cutoff Current I
EBO
100 nA V
EB
=4V
Collector Emitter
Cutoff Current
I
CES
100 nA V
CES
=16V
Collector-Emitter
Saturation Voltage
V
CE(sat)
7
70
130
15
150
200
mV
mV
mV
I
C
=0.1A, I
B
=10mA*
I
C
=1A, I
B
=10mA*
I
C
=2.5A, I
B
=50mA*
Base-Emitter
Saturation Voltage
V
BE(sat)
0.89 1.0 V I
C
=2.5A, I
B
=50mA*
Base-Emitter Turn-On
Voltage
V
BE(on)
0.79 1.0 V I
C
=2.5A, V
CE
=2V*
Static Forward
Current Transfer
Ratio
h
FE
200
300
200
100
400
450
360
180
I
C
=10mA, V
CE
=2V*
I
C
=200mA, V
CE
=2V*
I
C
=2A, V
CE
=2V*
I
C
=6A, V
CE
=2V*
Transition
Frequency
f
T
100 140 MHz I
C
=50mA, V
CE
=10V
f=100MHz
Output Capacitance C
obo
23 30 pF V
CB
=10V, f=1MHz
Turn-On Time t
on
170 V
CC
=10V, I
C
=1A
I
B1
=-I
B2
=10mA
Turn-Off Time t
off
400
*Measured under pulsed conditions. Pulse width=300 µ s. Duty cycle ≤ 2%
For typical characteristics graphs see SuperSOT FMMT618 datasheet.
ZDT6718
PNP TRANSISTOR
ELECTRICAL CHARACTERISTICS (at T amb = 25°C unless otherwise stated).
PARAMETER SYMBOL MIN. TYP. MAX. UNIT CONDITIONS.
Collector-Base
Breakdown Voltage
V
(BR)CBO
-20 -65 V I
C
=-100 µ A
Collector-Emitter
Breakdown Voltage
V
(BR)CEO
-20 -55 V I
C
=-10mA*
Emitter-Base
Breakdown Voltage
V
(BR)EBO
-5 -8.8 V I
E
=-100 µ A
Collector Cutoff
Current
I
CBO
-100 nA V
CB
=-15V
Emitter Cutoff
Current
I
EBO
-100 nA V
EB
=-4V
Collector Emitter
Cutoff Current
I
CES
-100 nA V
CES
=-15V
Collector-Emitter
Saturation Voltage
V
CE(SAT)
-16
-130
-145
-40
-200
-220
mV
mV
mV
I
C
=-0.1A, I
B
=-10mA*
I
C
=-1A, I
B
=-20mA*
I
C
=-1.5A, I
B
=-50mA*
Base-Emitter
Saturation Voltage
V
BE(SAT)
-0.87 -1.0 V I
C
=-1.5A, I
B
=-50mA*
Base-Emitter
Turn-On Voltage
V
BE(ON)
-0.81 -1.0 V I
C
=-2A, V
CE
=-2V*
Static Forward
Current Transfer
Ratio
h
FE
300
300
150
50
15
475
450
230
70
30
I
C
=-10mA, V
CE
=-2V*
I
C
=-100mA, V
CE
=-2V*
I
C
=-2A, V
CE
=-2V*
I
C
=-4A, V
CE
=-2V*
I
C
=-6A, V
CE
=-2V*
Transition
Frequency
f
T
150 180 MHz I
C
=-50mA, V
CE
=-10V
f=100MHz
Output Capacitance C
obo
21 30 pF V
CB
=-10V, f=1MHz
Turn-On Time t
on
40 V
CC
=-10V, I
C
=-1A
I
B1
=I
B2
=20mA
Turn-Off Time t
off
670
*Measured under pulsed conditions. Pulse width=300 µ s. Duty cycle ≤ 2%
For typical characteristics graphs see SuperSOT FMMT718 datasheet.
ZDT6718
