QZX363C5V6 - QZX363C20
Ordering Information
(Note 7)
Device
Packaging
Shipping
QZX363C5V6-7-F
SOT-363
3000/Tape & Reel
QZX363C6V8-7-F
SOT-363
3000/Tape & Reel
QZX363C12-7-F
SOT-363
3000/Tape & Reel
QZX363C15-7-F
SOT-363
3000/Tape & Reel
QZX363C20-7-F
SOT-363
3000/Tape & Reel
Notes:
7. For packaging details, go to our w.
Marking Information
xxx
YM
xxx= Product Type Marking Code
(See Electrical Characteristics Table)
YM = Date Code Marking
Y = Year (ex: N = 2002)
M = Month (ex: 9 = September)
Date Code Key
Year
2000
2001
2002
2003
2004
2005
2006
2007
2008
2009
2010
2111
2012
Code
L
M
N
P
R
S
T
U
V
W
X
Y
Z
Month
Jan
Feb
Mar
Apr
May
Jun
Jul
Aug
Sep
Oct
Nov
Dec
Code
1
2
3
4
5
6
7
8
9
O
N
D
Package Outline Dimensions
A
M
J
L
D
B C
H
K
F
SOT-363
Dim
Min
Max
A
0.10
0.30
B
1.15
1.35
C
2.00
2.20
D
0.65 Nominal
F
0.40
0.45
H
1.80
2.20
J
0
0.10
K
0.90
1.00
L
0.25
0.40
M
0.10
0.22
α
0° 8°
All Dimensions in mm
DQZX363C5V6-QZX363C20
Document number: DS30143 Rev. 13 - 2
3 of 4
www.diodes.com
June 2008
© Diodes Incorporated
Suggested Pad Layout
X
Z
Y
C
E
E
G
Dimensions
Value (in mm)
Z
2.5
G
1.3
X
0.42
Y
0.6
C
1.9
E
0.65
