SDM20E40C
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
40 V
RMS Reverse Voltage
V
R(RMS)
28 V
Forward Continuous Current (Note 6)
I
FM
0.4 A
Non-Repetitive Peak Forward Surge Current
@ t = 8.3ms
I
FSM
2 A
Repetitive peak Forward Current
I
FRM
500 mA
Thermal Characteristics
Characteristic Symbol
Value
Unit
Power Dissipation (Note 6)
P
D
400 mW
Operating Temperature Range
T
OP
-30 to +85
°C
Junction Temperature Range
T
J
-30 to +125
°C
Storage Temperature Range
T
STG
-40 to +125
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Reverse Breakdown Voltage (Note 7)
V
(BR)R
40
⎯
⎯
V
I
R
= 500
μA
Forward Voltage
V
F
⎯
⎯
⎯
⎯
300
500
mV
I
F
= 10mA
I
F
= 200mA
Leakage Current (Note 7)
I
R
⎯
⎯
70
μA
V
R
= 25V
Total Capacitance
C
T
⎯
⎯
100 pF
V
R
= 0V, f = 1.0MHz
Notes:
6. Mounted on FR4 PC Board with recommended pad layout which can be found on our website 7. Short duration pulse test used to minimize self-heating effect.
0.1
1.0
10
100
1,000
I
, INS
T
AN
T
ANE
O
U
S
F
O
R
WA
R
D
C
U
R
R
EN
T
(mA
)
F
0
V , INSTANTANEOUS FORWARD VOLTAGE (mV)
Fig. 1 Typical Forward Characteristics
