UF5A600D1
Document number: DS32143 Rev. 3 - 2
2 of 4
December 2010
© Diodes Incorporated
UF5A600D1
NEW PROD
UC
T
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
600 V
Average Rectified Output Current
I
O
5 A
Non-Repetitive Peak Forward Surge Current
8.3ms Single Half Sine-Wave Superimposed on Rated Load
I
FSM
100 A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Typical Thermal Resistance Junction to Case
R
θJC
2.0
°C/W
Typical Thermal Resistance Junction to Ambient (Note 3)
R
θJA
34
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +175
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage
V
F
⎯
⎯
1.4
1.1
1.9
1.75
V
I
F
= 5A, T
J
= 25
°C
I
F
= 5A, T
J
= 125
°C
Reverse Leakage Current (Note 4)
I
R
⎯
⎯
⎯
⎯
10
0.2
μA
mA
V
R
= 600V, T
J
= 25
°C
V
R
= 600V, T
J
= 125
°C
Reverse Recovery Time
t
rr
⎯
⎯
22
20
30
25
ns
I
F
= 0.5A, I
R
= 1.0A, I
rr
= 0.25A
I
F
= 1A, V
R
= 30V, di/dt = 100A/
μs
Maximum Junction Capacitance
C
J
⎯
27 50 pf
V
R
= 10V
DC
, f = 1MHz
Notes:
3. Device mounted on Polymide PCB, with 16X recommended pad layout.
4. Short duration pulse test used to minimize self-heating effect.
0
1
2
3
4
5
6
0
1
2
3
4
5
6
Fig. 1 Forward Power Dissipation
I
, AVERAGE FORWARD CURRENT (A)
F(AV)
P
,
P
O
WE
R
DI
SSI
P
A
T
IO
N (
W
)
D
0.0001
0.001
0.01
0.1
1
10
100
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
F
0
0.4
0.8
1.2
1.6
2.0
2.4
I,
I
N
S
T
A
N
T
A
N
E
O
U
S
F
O
R
WA
R
D
C
U
R
R
E
N
T
(A
)
F
T = 150°C
A
T = -55°C
A
T = 25°C
A
T = 125°C
A
T = 85°C
A
