e

3

DS25004 Rev. 8 - 2

1 of 3

UF3001 - UF3007

www.diodes.com

ã

Diodes Incorporated

UF3001 - UF3007

3.0A ULTRA-FAST RECTIFIER

Features

DO-201AD

Dim

Min

Max

A

25.40

¾

B

7.20

9.50

C

1.20

1.30

D

4.80

5.30

All Dimensions in mm

A

A

B

C

D

Maximum Ratings and Electrical Characteristics

@ T

A

= 25

°

C unless otherwise specified

·

Diffused Junction

·

Ultra-Fast Switching for High Efficiency

·

Surge Overload Rating to 150A Peak

·

Low Reverse Leakage Current

·

Lead Free Finish, RoHS Compliant (Note 4)

Mechanical Data

·

Case: DO-201AD

·

Case Material: Molded Plastic

.

UL Flammability

Classification Rating 94V-0

·

Moisture Sensitivity: Level 1 per J-STD-020C

·

Terminals: Finish - Tin. Plated Leads Solderable per
MIL-STD-202, Method 208

·

Polarity: Cathode Band

·

Marking: Type Number

·

Ordering Information: See Last Page

·

Weight: 1.1 grams (approximate)

Characteristic

Symbol

UF

3001

UF

3002

UF

3003

UF

3004

UF

3005

UF

3006

UF

3007

Unit

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage
DC Blocking Voltage (Note 5)

V

RRM

V

RWM

V

R

50

100

200

400

600

800

1000

V

RMS Reverse Voltage

V

R(RMS)

35

70

140

280

420

560

700

V

Average Rectified Output Current
(Note 1)

@ T

A

= 55

°

C

I

O

3.0

A

Non-Repetitive Peak Forward Surge Current

8.3ms Single half sine-wave Superimposed on Rated Load

I

FSM

150

A

Forward Voltage

@ I

F

= 3.0A

V

FM

1.0

1.3

1.7

V

Peak Reverse Current

@ T

A

= 25

°

C

at Rated DC Blocking Voltage (Note 5)

@ T

A

= 100

°

C

I

RM

5.0

100

m

A

Reverse Recovery Time (Note 3)

t

rr

50

75

ns

Typical Total Capacitance (Note 2)

C

T

75

50

pF

Typical Thermal Resistance Junction to Ambient

R

q

JA

35

°C/W

Operating and Storage Temperature Range

T

j,

T

STG

-65 to +150

°

C

Notes: 1. Valid provided that leads are maintained at ambient temperature at a distance of 9.5mm from the case.

2. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.

3. Measured with I

F

= 0.5A, I

R

= 1.0A, I

rr

= 0.25A. See Figure 5.

4. RoHS revision 13.2.2003. High temperature solder exemption applied, see EU Directive Annex Note 7.
5. Short duration pulse test used to minimize self-heating effect

.

Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
