Features
PR6001 - PR6005
6.0A FAST RECOVERY RECTIFIER
Maximum Ratings and Electrical Characteristics
@ T
A
= 25
°C unless otherwise specified
·
Diffused Junction
·
Fast Switching for High Efficiency
·
High Current Capability and Low Forward Voltage Drop
·
Surge Overload Rating to 300A Peak
·
Low Reverse Leakage Current
·
Lead Free Finish, RoHS Compliant (Note 4)
Mechanical Data
·
Case: R-6
·
Case Material: Molded Plastic
.
UL Flammability
Classification Rating 94V-0
·
Moisture Sensitivity: Level 1 per J-STD-020C
·
Terminals: Finish - Bright Tin. Plated Leads Solderable per
MIL-STD-202, Method 208
·
Polarity: Cathode Band
·
Ordering Information: See Last Page
·
Marking: Type Number
·
Weight: 2.1 grams (approximate)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic
Symbol
PR
6001
PR
6002
PR
6003
PR
6004
PR
6005
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
50
100
200
400
600
V
RMS Reverse Voltage
V
R(RMS)
35
70
140
280
420
V
Average Rectified Output Current
(Note 1)
@ T
A
= 60
°C
I
O
6.0
A
Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave Superimposed on Rated Load
(JEDEC Method)
I
FSM
300
A
Forward Voltage
@ I
F
= 6.0A
V
FM
1.2
V
Peak Reverse Current
@ T
A
= 25
°C
at Rated DC Blocking Voltage
@ T
A
= 125
°C
I
RM
10
150
mA
Reverse Recovery Time (Note 3)
t
rr
150
250
ns
Typical Junction Capacitance (Note 2)
C
j
140
70
pF
Typical Thermal Resistance Junction to Ambient
R
qJA
32
K/W
Operating and Storage Temperature Range
T
j,
T
STG
-65 to +150
°C
Notes: 1. Valid provided that leads are maintained at ambient temperature at a distance of 9.5mm from the case.
2. Measured at 1.0MHz and applied reverse voltage of 4.0 V DC.
3. Measured with I
F
= 0.5A, I
R
= 1.0A, I
rr
= 0.25 A. See figure 5.
4. RoHS revision 13.2.2003. Glass and High Temperature Solder Exemptions Applied, see
EU Directive Annex Notes 5 and 7.
A
A
B
C
D
R-6
Dim
Min
Max
A
25.40
¾
B
8.60
9.10
C
1.20
1.30
D
8.60
9.10
All Dimensions in mm
