SBRT20U60SP5
Document number: DS36825 Rev. 3 - 2
3 of 4
www.diodes.com
March 2014
© Diodes Incorporated
SBRT20U60SP5
NEW PROD
UC
T
ADVANCED INFORMATION
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
I
, INS
TAN
TANE
O
U
S
R
EVE
R
SE
C
U
R
R
EN
T
(µ
A
)
R
V , INSTANTANEOUS REVERSE VOLTAGE (V)
R
Figure 3 Typical Reverse Characteristics
10
100
1000
10000
100000
0 10 20 30 40 50 60
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
V , DC REVERSE VOLTAGE (V)
R
Figure 4 Total Capacitance vs. Reverse Voltage
C
, T
O
TAL
C
A
P
A
C
IT
AN
C
E (
p
F
)
T
100
1000
10000
100000
0 5 10 15 20 25 30 35 40
f = 1MHz
0.00
5.00
10.00
15.00
20.00
25.00
25 50 75 100 125 150
Figure 5 Forward Current Derating Curve
T , AMBIENT TEMPERATURE (°C)
L
I
, A
V
ERAGE
RECT
IF
IE
D OUT
P
UT
C
URRENT
(
A
)
O
With Heatsink (Note 6)
Without Heatsink
POWERDI ® 5
Dim Min Max
A 1.05 1.15
A2 0.33 0.43
b1 0.80 0.99
b2 1.70 1.88
D 3.90 4.05
D2 3.054 Typ
E 6.40 6.60
e 1.84 Typ
E1 5.30 5.45
E2 3.549
Typ
L 0.75 0.95
L1 0.50 0.65
W 1.10 1.41
All Dimensions in mm
E
E1
b1
A
A2
A2
D
b2
b1
e
D2
L
E2
L1
W
