SBRT15U100SP5
Document number: DS36524 Rev. 4 - 2
2 of 4
March 2014
© Diodes Incorporated
SBRT15U100SP5
NEW PROD
UC
T
ADVANCED INFORMATION
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
100 V
Average Rectified Output Current
I
O
15 A
Non-Repetitive Peak Forward Surge Current 8.3mS
I
FSM
250 A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Typical Thermal Resistance Junction to Ambient (Note 6)
R
θJA
15 °C/W
Typical Thermal Resistance Junction to Lead (Note 6)
R
θJC
1 °C/W
Operating and Storage Temperature Range
T
J,
T
STG
-65 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Notes:
6. Device with additional heatsink, (copper pad on aluminum substrate 30mm*30mm + Aluminum heatsink 50mm*50mm*22mm)
7. Short duration pulse test used to minimize self-heating effect.
P
, POW
E
R DIS
S
IP
A
T
ION (
W
)
D
0
1
2
3
4
5
6
7
8
9
10
0
5
10
15
20
I , AVERAGE RECTIFIED OUTPUT CURRENT (A)
Figure 1 Forward Power Dissipation
O
Note 6
0.0001
0.001
0.01
0.1
1
10
100
0
100
200
300
400
500
600
700
Figure 2 Typical Forward Characteristics
V , INSTANTANEOUS FORWARD VOLTAGE (mV)
F
I
, INST
A
N
TA
NEOUS
F
O
RW
ARD C
URRENT
(
A
)
F
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
T = -55°C
A
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop
V
F
—
—
—
—
0.44
0.59
0.64
0.56
—
0.65
0.70
0.64
V
I
F
=5A, T
J
= +25°C
I
F
=12A, T
J
= +25°C
I
F
=15A, T
J
= +25°C
I
F
=15A, T
J
= +125°C
Leakage Current (Note 7)
I
R
—
—
40
—
250
15
μA
mA
V
R
= 100V , T
J
= +25°C
V
R
= 100V , T
J
= +125°C
