Diodes SBR60A60CT User Manual
Sbr60a60ct, Features, Mechanical data

SBR60A60CT
Document number: DS31096 Rev. 5 - 2
1 of 3
April 2009
© Diodes Incorporated
SBR60A60CT
SBR is a registered trademark of Diodes Incorporated.
60A SBR
®
SUPER BARRIER RECTIFIER
Features
•
Low Forward Voltage Drop
• Low
Leakage
Current
•
Excellent High Temperature Stability
•
Patented Super Barrier Rectifier Technology
•
Soft, Fast Switching Capability
•
150ºC Operating Junction Temperature
•
Lead Free Finish, RoHS Compliant (Note 2)
•
Also Available in Green Molding Compound (Note 4)
Mechanical Data
• Case:
TO-220AB
•
Case Material: Molded Plastic, UL Flammability Classification
Rating 94V-0
•
Terminals: Matte Tin Finish annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208
•
Marking Information: See Page 2
•
Ordering Information: See Page 2
•
Weight: 1.85 grams (approximate)
Maximum Ratings (Per Leg)
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
60 V
Average Rectified Output Current
(Per Leg)
(Total)
I
O
30
60
A
Non-Repetitive Peak Forward Surge Current 8.3mS
Single Half Sine-Wave Superimposed on rated load
I
FSM
280 A
Thermal Characteristics (Per Leg)
Characteristic Symbol
Value
Unit
Typical Thermal Resistance, Junction to Case
R
θJC
2 ºC/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
ºC
Electrical Characteristics
(Per Leg)
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop
V
F
-
0.50
0.61
0.46
-
0.53
0.65
0.49
0.64
V
I
F
= 15A, T
J
= 25ºC
I
F
= 30A, T
J
= 25ºC
I
F
= 15A, T
J
= 125ºC
I
F
= 30A, T
J
= 125ºC
Leakage Current (Note 1)
I
R
-
0.07
15
0.2
100
mA
V
R
= 60V, T
J
= 25ºC
V
R
= 60V, T
J
= 125ºC
Notes:
1. Short duration pulse test used to minimize self-heating effect.
2. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
Package Pin Out
Configuration
TO-220AB
Top View
TO-220AB
Bottom View
