SBR60A45CT
Document number: DS31320 Rev. 3 - 2
1 of 3
February 2009
© Diodes Incorporated
SBR60A45CT
SBR is a registered trademark of Diodes Incorporated.
60A SBR
®
SUPER BARRIER RECTIFIER
Features
•
Low Forward Voltage Drop
•
Excellent High Temperature Stability
•
Patented Super Barrier Rectifier Technology
•
Soft, Fast Switching Capability
•
150ºC Operating Junction Temperature
•
Lead Free Finish, RoHS Compliant (Note 2)
•
Also Available in Green Molding Compound (Note 5)
Mechanical Data
• Case:
TO-220AB
•
Case Material: Molded Plastic, UL Flammability Classification
Rating 94V-0
•
Terminals: Matte Tin Finish annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208
•
Marking Information: See Page 2
•
Ordering Information: See Page 2
•
Weight: 1.85 grams (approximate)
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
45 V
Average Rectified Output Current @ T
C
= 150ºC
I
O
60 A
Non-Repetitive Peak Forward Surge Current 8.3mS
Single Half Sine-Wave Superimposed on rated load
I
FSM
280 A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Typical Thermal Resistance (Per Leg)
Thermal Resistance Junction to Case
R
θJC
2
ºC/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
ºC
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop (per leg)
V
B
F
B
-
0.50
0.49
0.55
0.53
V
I
B
F
B
= 30A, T
J
= 25ºC
I
B
F
B
= 30A, T
J
= 125ºC
Leakage Current (Note 1)
I
B
R
B
-
0.25
20
1
200
mA
V
B
R
B
= 45V, T
J
= 25ºC
V
B
R
B
= 45V, T
J
= 125ºC
Notes:
1. Short duration pulse test used to minimize self-heating effect.
2. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied,
TO-220AB
Top View
TO-220AB
Bottom View
Package Pin Out
Configuration
