ZHCS1000
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Units
Continuous Reverse Voltage V
R
40 V
Continuous Forward Current I
F
1 A
Forward Voltage @ I
F
= 1A (typ) V
F
425 mV
Average Peak Forward Current; D.C. = 50% I
FAV
1750 mA
Non Repetitive Forward Current
t 100μs
I
FSM
12 A
t 10ms 5.2 A
Thermal Characteristics
Characteristic Symbol Value Unit
Power Dissipation, T
A
= +25°C P
D
500 mW
Junction Temperature T
J
+125 °C
Storage Temperature Range T
STG
-55 to +150 °C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Reverse Breakdown Voltage V
(BR)R
40 60 — V I
R
= 300μA
Forward Voltage (Note 5) V
F
— 240 270
mV
I
F
= 50mA
— 265 290 I
F
= 100mA
— 305 340 I
F
= 250mA
— 355 400 I
F
= 500mA
— 390 450 I
F
= 750mA
— 425 500 I
F
= 1A
— 495 600 I
F
= 1.5A
— 420 — I
F
= 1A, T
A
= +100°C
Reverse Current (Note 6) I
R
— 50 100 μA V
R
= 30V
Total Capacitance C
T
— 25 — pF f = 1MHz, V
R
= 30V
Reverse Recovery Time trr — 12 — ns
Switched from I
F
= 500mA to
I
R
= 500mA
Measured @ I
R
= 50mA
Notes: 5. Measured under pulsed conditions. Pulse width = 300μS.
6. Short duration pulse test used to minimize self-heating effect.
