SBR is a registered trademark of Diodes Incorporated.
SBRT40V100CT
Document number: DS36246 Rev. 4 - 2
2 of 4
March 2014
© Diodes Incorporated
SBRT40V100CT
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
100 V
Average Rectified Output Current (Per leg)
(Total)
I
O
20
40
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load (per leg)
I
FSM
180 A
Thermal Characteristics
(Per Leg)
Characteristic Symbol
Value
Unit
Typical Thermal Resistance Junction to Ambient (Note 5)
R
θJA
10 °C/W
Operating and Storage Temperature Range
T
J,
T
STG
-55 to +150
°C
Electrical Characteristics
(Per Leg)
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop (Note 6)
V
F
—
—
0.41
0.52
0.67
—
—
0.58
0.73
0.65
V
I
F
= 5A, T
J
= +25°C
I
F
= 10A, T
J
= +25°C
I
F
= 20A, T
J
= +25°C
I
F
= 20A, T
J
= +125°C
Leakage Current (Note 6)
I
R
—
—
0.07
20
0.3
—
mA
V
R
= 100V, T
J
= +25°C
V
R
= 100V, T
J
= +125°C
Notes:
5. Test with additional heatsink (Black Aluminum, 37*50*15mm).
6. Short duration pulse test used to minimize self-heating effect.
I , AVERAGE RECTIFIED OUTPUT CURRENT (A)
Figure 1 Forward Power Dissipation
O
P
,
P
O
WE
R
DISS
IP
A
T
IO
N
(W
)
D
0
2
4
6
8
10
12
14
16
0
5
10
15
20
25
T = 150
J
Note 5
V , INSTANTANEOUS FORWARD VOLTAGE (mV)
F
Figure 2 Typical Forward Characteristics
I,
IN
S
TA
N
TA
N
E
O
U
S F
O
R
WA
R
D
C
U
R
R
E
N
T
(A
)
F
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
0.0001
0.001
0.01
0.1
1
10
100
0
100
200
300
400
500
600
700
T = -55°C
A
