SBR40100CT
Document number: DS30988 Rev. 6 - 2
2 of 5
May 2012
© Diodes Incorporated
SBR40100CT
SBR40100CTFP
SBR is a registered trademark of Diodes Incorporated.
Maximum Ratings (Per Leg)
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
100 V
Average Rectified Output Current Per Device
(Per Leg)
(Total)
I
O
20
40
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
280 A
Peak Repetitive Reverse Surge Current (2uS-1Khz)
I
RRM
2 A
Isolation Voltage (ITO-220AB Only)
From terminal to heatsink t = 3 sec.
V
AC
2000 V
Thermal Characteristics (Per Leg)
Characteristic Symbol
Value
Unit
Typical Thermal Resistance
Package = TO-220AB
Package = ITO-220AB
R
θJC
2
4
ºC/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +175
ºC
Electrical Characteristics (Per Leg)
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop
V
F
- -
0.82
V
I
F
= 20A, T
J
= 25ºC
- 0.68
0.73
I
F
= 20A, T
J
= 125ºC
Leakage Current (Note 6)
I
R
- -
0.1
mA
V
R
= 100V, T
J
= 25ºC
- - 10
V
R
= 100V, T
J
= 125ºC
Notes:
6. Short duration pulse test used to minimize self-heating effect.
