SBR3M30P1
SBR and POWERDI are registered trademarks of Diodes Incorporated.
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
30 V
RMS Reverse Voltage
V
R(RMS)
21 V
Average Rectified Output Current (See Figure 1)
I
O
3.0 A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
75 A
Non-Repetitive Avalanche Energy (Per Element)
(T
J
= 25ºC, I
AS
= 5A, L = 8.5mH)
E
AS
105 mJ
Repetitive Peak Avalanche Energy (Per Element)
(1
μs, 25ºC)
P
ARM
1100 W
Thermal Characteristics
Characteristic Symbol
Value
Unit
Maximum Thermal Resistance
Thermal Resistance Junction to Soldering (Note 3)
Thermal Resistance Junction to Ambient (Note 4)
Thermal Resistance Junction to Ambient (Note 5)
R
θJS
R
θJA
R
θJA
5
183
125
ºC/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +175
ºC
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Reverse Breakdown Voltage (Note 6)
V
(BR)R
30 - - V
I
R
= 250µA
Forward Voltage Drop
V
F
-
-
-
-
-
-
0.26
0.37
0.46
0.16
0.29
0.42
0.30
0.41
0.50
0.19
0.32
0.45
V
I
F
= 0.1A, T
J
= 25ºC
I
F
= 1.0A, T
J
= 25ºC
I
F
= 3.0A, T
J
= 25ºC
I
F
= 0.1A, T
J
= 125ºC
I
F
= 1.0A, T
J
= 125ºC
I
F
= 3.0A, T
J
= 125ºC
Leakage Current (Note 6)
I
R
-
8.5
19
1.7
3.1
100
200
15
20
µA
µA
mA
mA
V
R
= 5V, T
J
= 25ºC
V
R
= 30V, T
J
= 25ºC
V
R
= 5V, T
J
= 125ºC
V
R
= 30V, T
J
= 125ºC
Notes:
3. Theoretical R
θJS
calculated from the top center of the die straight down to the PCB cathode tab solder junction.
4. FR-4 PCB, 2 oz. Copper, minimum recommended pad lay5. Polymide PCB, 2 oz. Copper, minimum recommended pad layout pe
6. Short duration pulse test used to minimize self-heating effect.
