SBR3150SB
Document number: DS35402 Rev. 3 - 2
2 of 4
January 2012
© Diodes Incorporated
SBR3150SB
ADVAN
CE I
N
F
O
RM
ATI
O
N
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
150 V
Average Rectified Output Current
@ T
T
=100
°C I
O
3.0 A
Non-Repetitive Peak Forward Surge Current 8.3ms
single half sine-wave superimposed on rated load
I
FSM
80 A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Typical Thermal Resistance, Junction to Ambient (Note 4)
R
θJA
104
°C/W
Operating Temperature Range
T
J
150
Storage Temperature Range
T
STG
-65+150
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop
V
F
- 0.74
0.82
V
I
F
= 3.A, T
J
= 25
°C
- 0.61
0.67
I
F
= 3.A, T
J
= 125
°C
Leakage Current
I
R
-
-
-
-
0.5
20
mA
V
R
= 150V, T
J
= 25
°C
V
R
= 150V, T
J
= 125
°C
Notes:
4. FR-4 PCB, 2 oz. Copper, minimum recommended pad lay
A
= 25ºC
0
0.2
0.4
0.6
0.8
1.0
0.01
1
10
100
I
, INS
T
AN
T
ANE
O
U
S
F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F
0.1
Fig. 1 Typical Forward Characteristics
V , INSTANTANEOUS FORWARD VOLTAGE (V)
F
T = 25°C
A
T = 75°C
A
T = 100°C
A
T = 125°C
A
T = 150°C
A
0.1
1
10
100
I,
I
N
S
T
AN
T
AN
E
O
U
S
R
EV
E
R
SE
C
U
R
R
EN
T
(m
A
)
R
0.001
0.01
0
25
50
75
100
125
150
Fig. 2 Typical Reverse Characteristics
V , INSTANTANEOUS REVERSE VOLTAGE (V)
R
T = 75°C
A
T = 100°C
A
T = 125°C
A
T = 150°C
A
T = 25°C
A
