SBR3060
Document number: DS30969 Rev. 6 - 2
2 of 5
www.diodes.com
October 2011
© Diodes Incorporated
SBR3060CT
SBR3060CTFP
SBR is a registered trademark of Diodes Incorporated.
Maximum Ratings (Per Leg)
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V RRM
V
RWM
V
RM
60 V
Average Rectified Output Current Per Leg
Total I
O
15
30
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
200 A
Peak Repetitive Reverse Surge Current (2uS-1Khz) I
RRM
2 A
Isolation Voltage (ITO-220AB Only)
From terminal to heatsink t = 3 sec.
V
AC
2000 V
Thermal Characteristics (Per Leg)
Characteristic Symbol Value Unit
Maximum Thermal Resistance (per leg)
Package = TO-220AB
Package = ITO-220AB
R θJC 2
4 ºC/W
Operating and Storage Temperature Range T
J
, T
STG
-65 to +150 ºC
Electrical Characteristics (Per Leg)
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Min Typ Max Unit Test Condition
Reverse Breakdown Voltage (Note 4) V
(BR)R
60 - - V I
R
= 0.5mA
Forward Voltage Drop V F
-
-
0.62
0.70
0.65
V
I F = 15A, T J = 25ºC
I F = 15A, T J = 125ºC
Leakage Current (Note 4) I
R
- -
0.5
100
mA
V
R
= 60V, T
J
= 25ºC
V
R
= 60V, T
J
= 125ºC
Notes: 4. Short duration pulse test used to minimize self-heating effect.
