SBR30300
Document number: DS30995 Rev. 6 - 2
2 of 5
www.diodes.com
September 2011
© Diodes Incorporated
SBR30300CT
SBR30300CTFP
SBR is a registered trademark of Diodes Incorporated.
Maximum Ratings (Per Leg)
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V
RRM
V
RWM
V
RM
300 V
Average Rectified Output Current Per Device (Per Leg)
(Total)
I
O
15
30
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
200 A
Peak Repetitive Reverse Surge Current (2uS-1Khz) I RRM
2 A
Isolation Voltage (ITO-220AB Only)
From terminal to heatsink t = 3 sec.
V
AC
2000 V
Thermal Characteristics (Per Leg)
Characteristic Symbol Value Unit
Typical Thermal Resistance
Package = TO-220AB
Package = ITO-220AB
R θJC 2
4 ºC/W
Operating and Storage Temperature Range T
J
, T
STG
-65 to +175 ºC
Electrical Characteristics (Per Leg)
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Min Typ Max Unit Test Condition
Forward Voltage Drop V F
-
-
0.76
1.03
0.92
V
I F = 15A, T J = 25ºC
I F = 15A, T J = 125ºC
Leakage Current (Note 4) I
R
- -
0.1
10
mA
V
R
= 300V, T
J
= 25ºC
V
R
= 300V, T
J
= 125ºC
Reverse Recovery Time t
rr
- 25 30
ns
I
F
= 0.5A, I
R
= 1A, I
RR
= 0.25A
- 28 35
I F = 1A, V R = 30V
di/dt = 100A/
μs, T
J
= 25ºC
Notes: 4. Short duration pulse test used to minimize self-heating effect.
