Diodes SBR30100CTFP - Manual (Page 2)

SBR is a registered trademark of Diodes Incorporated.
SBR30100
Document number: DS30970 Rev. 6 - 2
2 of 5
www.diodes.com
May 2012
© Diodes Incorporated
SBR30100CT
SBR30100CTFP
Maximum Ratings (Per Leg)
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V RRM
V
RWM
V
RM
100 V
Average Rectified Output Current (Per Leg)
(Total)
I
O
15
30
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
200 A
Peak Repetitive Reverse Surge Current (2 μS-1Khz) I
RRM
2 A
Isolation Voltage (ITO-220AB Only)
From terminal to heatsink t = 3 sec.
V
AC
2000 V
Thermal Characteristics (Per Leg)
Characteristic Symbol Value Unit
Typical Thermal Resistance
Package = TO-220AB
Package = ITO-220AB
R θJC 2
4 ºC/W
Operating and Storage Temperature Range T J , T STG
-65 to +175 ºC
Electrical Characteristics (Per Leg)
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Min Typ Max Unit Test Condition
Forward Voltage Drop V F
-
-
0.72
0.85
0.75
V
I
F
= 15A, T
J
= 25ºC
I F = 15A, T J = 125ºC
Leakage Current (Note 6) I
R
- -
0.1
10
mA
V
R
= 100V, T
J
= 25ºC
V
R
= 100V, T
J
= 125ºC
Notes: 6. Short duration pulse test used to minimize self-heating effect.
7. Using heatsink (by black Aluminum 45mm * 20mm * 12mm)
0
2
4
6
8
10
12
14
0 5 10 15 20 25
Fig. 1 Forward Power Dissipation
I , AVERAGE FORWARD CURRENT (A)
F(AV)
P
,
P
O
WE
R
D
ISSI
P
A
T
IO
N
(W
)
D
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
F
0.1
1
10
100
I,
I
N
S
T
AN
T
AN
E
O
U
S
F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F
0.01
