SBR1U400P1
Document number: DS31877 Rev. 3 - 2
2 of 5
February 2013
© Diodes Incorporated
SBR1U400P1
SBR and POWERDI are registered trademarks of Diodes Incorporated.
NEW PROD
UC
T
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
400 V
Average Rectified Output Current (See Figure 1)
I
O
1.0 A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
40 A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Maximum Thermal Resistance Junction to Ambient (Note 5)
R
θJA
217 °C/W
Maximum Thermal Resistance Junction to Ambient (Note 6)
R
θJA
138 °C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +175
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage
V
F
—
—
0.82
—
0.90
0.80
V
I
F
= 1.0A, T
J
= +25°C
I
F
= 1.0A, T
J
= +125°C
Reverse Current (Note 7)
I
R
— — 50 µA
V
R
= 400V, T
J
= +25°C
Reverse Recovery Time
t
rr
— — 85 ns
I
F
= 0.5A, I
R
= 1A,
I
RR
= 0.25A
Notes:
5. FR-4 PCB, 2 oz. Copper, minimum recommended pad lay
0
200
400
600
800
1,000
V , INSTANTANEOUS FORWARD VOLTAGE (mV)
F
Figure 1 Typical Forward Characteristics
0.00001
0.001
0.01
0.1
1
I,
IN
S
TA
N
TA
N
E
O
U
S
F
O
R
WA
R
D
C
U
R
R
E
N
T
(A
)
F
0.0001
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
0
50
100 150
200
250
300
350 400
0.01
0.1
1
10
100
1,000
I
, IN
S
TAN
TANE
O
U
S
R
EV
E
R
SE
C
U
R
R
EN
T
(µ
A
)
R
V , INSTANTANEOUS REVERSE VOLTAGE (V)
R
Figure 2 Typical Reverse Characteristics
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
