SBR1U200P1
SBR and PowerDI are registered trademarks of Diodes Incorporated.
NEW PROD
UC
T
1.0A SBR
®
SURFACE MOUNT SUPER BARRIER RECTIFIER
PowerDI
®
123
Features
•
Ultra Low Forward Voltage Drop
• Low
Leakage
Current
•
Superior Reverse Avalanche Capability
•
Excellent High Temperature Stability
•
Patented Interlocking Clip Design for High Surge Current
Capacity
•
Patented Super Barrier Rectifier Technology
•
Soft, Fast Switching Capability
•
150ºC Operating Junction Temperature
•
Lead Free Finish, RoHS Compliant (Note 1)
•
“Green” Molding Compound (No Br, Sb)
Mechanical Data
• Case:
PowerDI
®
123
•
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Polarity Indicator: Cathode Band
•
Terminals: Finish - Matte Tin annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208
•
Marking Information: See Page 3
•
Ordering Information: See Page 3
•
Weight: 0.018 grams (approximate)
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
200 V
Average Rectified Output Current (See Figure 1)
I
O
1.0 A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
40 A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Maximum Thermal Resistance Junction to Ambient (Note 2)
R
θJA
217
ºC/W
Maximum Thermal Resistance Junction to Ambient (Note 3)
R
θJA
138 ºC/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +175
ºC
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage
V
F
-
-
0.75
0.60
0.82
0.68
V
I
F
= 1.0A, T
J
= 25ºC
I
F
= 1.0A, T
J
= 125ºC
Reverse Current (Note 4)
I
R
- - 50
μA
V
R
= 200V, T
J
= 25ºC
Reverse Recovery Time
t
rr
- - 25
ns
I
F
= 0.5A, I
R
= 1A,
I
RR
= 0.25A,
Notes:
1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied, see EU Directive 2002/95/EC Annex Notes.
2. FR-4 PCB, 2 oz. Copper, minimum recommended pad lay
Top View
