SBR1A40SA
SBR is a registered trademark of Diodes Incorporated.
1.0A SBR
®
SUPER BARRIER RECTIFIER
SMA
Features
• Low
Leakage
Current
•
Patented Super Barrier Rectifier Technology
•
Soft, Fast Switching Capability
•
150ºC Operating Junction Temperature
•
Lead Free Finish, RoHS Compliant (Note 1)
•
Green Molding Compound (No Halogen and Antimony)
(Note 2)
Mechanical Data
• Case:
SMA
•
Case Material: Molded Plastic, UL Flammability Classification
Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Terminals: Lead Free Plating (Matte Tin Finish.) Solderable per
MIL-STD-202, Method 208
•
Polarity Indicator: Cathode Band
•
Weight: 0.064 grams (approximate)
Ordering Information
(Note 3)
Part Number
Case
Packaging
SBR1A40SA-13
SMA
5000/Tape & Reel
Notes:
1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied, see EU Directive 2002/95/EC Annex Notes.
2. No purposefully added lead. Halogen and Antimony Free.
3. For packaging details, go to our website at
Marking Information
Top View
Bottom View
Green
S D 4 = Product Type Marking Code
= Manufacturers’ code marking
YWW = Date Code Marking
Y = Last digit of year (ex: 9 for 2009)
WW = Week code (01 - 53)
YWW
S
D 4
XX
