SBR1A40S1

Document number: DS33306 Rev. 3 - 2

2 of 5

www.diodes.com

July 2011

© Diodes Incorporated

SBR1A40S1

NEW PROD

UC

T

SBR is a registered trademark of Diodes Incorporated.





Maximum Ratings

@T

A

= 25°C unless otherwise specified

Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.

Characteristic Symbol

Value

Unit

Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage

V

RRM

V

RWM

V

RM

40 V

Average Rectified Output Current T

C

= 65°C

I

O

1 A

Non-Repetitive Peak Forward Surge Current
8.3ms Single Half Sine-Wave Superimposed on Rated Load

I

FSM

20 A



Thermal Characteristics

Characteristic Symbol

Value

Unit

Maximum Thermal Resistance
Thermal Resistance Junction to Ambient (Note 4)
Thermal Resistance Junction to Ambient (Note 5)

R

θJA

R

θJA

473
407

ºC/W

Operating and Storage Temperature Range

T

J

, T

STG

-65 to +150

ºC


Power Dissipation (Note 7)


PD

R

θJC

320
147

mW

ºC/W



Electrical Characteristics

@T

A

= 25°C unless otherwise specified

Characteristic Symbol

Min

Typ

Max

Unit

Test

Condition

Forward Voltage Drop

V

F

- -

0.52

V

I

F

= 1A, T

J

= 25ºC

- 0.44

0.50

I

F

= 1A, T

J

= 125ºC

Leakage Current (Note 6)

I

R

- 18

200

µA

V

R

= 40V, T

J

= 25ºC

- 4 -

mA

V

R

= 40V, T

J

= 100ºC

Notes:

4. FR-4 PCB, 2 oz. Copper, minimum recommended pad layout per http://www.diodes.com.

5. Polymide PCB, 2 oz. Copper, minimum recommended pad layout pad layout per http://www.diodes.com.

6. Short duration pulse test used to minimize self-heating effect.

7. Device mounted on FR-4 substate,1”*1”,2oz, copper,singie-sided,PC boards.



0.0001

0.001

0.01

0.1

1

10

0

0.1

0.2

0.3

0.4

0.5

0.6

0.7

Fig.1 Typical Forward Characteristics

V , INSTANTANEOUS FORWARD VOLTAGE (V)

F

I

, IN

ST

A

N

T

A

NEOUS

F

O

R

W

ARD C

URR

ENT

(

A

)

F

T = 150°C

A

1

10

100

1,000

10,000

100,000

Fig. 2 Typical Reverse Characteristics

0

10

20

30

40

V , INSTANTANEOUS REVERSE VOLTAGE (V)

R

I

, I

N

S

T

A

N

T

A

NEO

U

S

REVER

SE CUR

RENT (

A

)

R

μ

T = 85°C

A

T = 125°C

A

T = 150°C

A

T = 25°C

A
