SBR12U120P5
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
120 V
Average Rectified Output Current (See Figure 1)
I
O
12 A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
250 A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Maximum Thermal Resistance Junction to Ambient (Note 6)
R
θJA
27 ºC/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
ºC
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop
V
F
-
-
-
0.63
0.80
0.68
V
I
F
= 12A, T
J
= +25ºC
I
F
= 12A, T
J
= +125ºC
Leakage Current (Note 7)
I
R
-
-
-
2
0.25
35
mA
V
R
= 120V, T
J
= +25ºC
V
R
= 120V, T
J
= +125ºC
Notes:
6. Device mounted on Polymide PCB with 16x recommended pad layout.
7. Short duration pulse test used to minimize self-heating effect.
