SBR12U100P5
NEW PROD
UC
T
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
100 V
Average Rectified Output Current (See Figure 1)
I
O
12 A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
250 A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Typical Thermal Resistance Junction to Ambient (Note 5) T
A
= +25°C
R
θJA
27 ºC/W
Typical Thermal Resistance Junction to Lead
R
θJL
3 ºC/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
ºC
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop
V
F
-
0.49
-
-
-
0.51
0.71
V
I
F
= 5A, T
J
= +25ºC
I
F
= 5A, T
J
= +125ºC
I
F
= 12A, T
J
= +25ºC
Leakage Current (Note 6)
I
R
-
-
11
0.25
40
mA
V
R
= 100V, T
J
= +25ºC
V
R
= 100V, T
J
= +125ºC
Notes:
5. Device mounted on Polymide PCB with 16x recommended pad layout.
6. Short duration pulse test used to minimize self-heating effect.
