SBR12A45SP5
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
45 V
Average Rectified Output Current
I
O
12 A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
280 A
Non-Repetitive Avalanche Energy
(T
J
= +25ºC, I
AS
= 2A, L = 8.5 mH)
E
AS
30
mJ
Thermal Characteristics
Characteristic Symbol
Value
Unit
Typical Thermal Resistance Junction to Case (Note 5)
R
θJC
3 ºC/W
Typical Thermal Resistance Junction to Ambient (Note 5)
R
θJA
27 ºC/W
Operating Temperature Range
V
R
≤ 80% V
RRM
T
J
-65 to +150
ºC
V
R
≤ 50% V
RRM
≤180
DC Forward Mode
≤200
Storage Temperature Range
T
STG
-65 to +175
ºC
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop
V
F
- 0.43 -
V
I
F
= 6A, T
J
= +25ºC
- 0.50
0.60
I
F
= 12A, T
J
= +25ºC
- 0.33 -
I
F
= 6A, T
J
= +125ºC
- 0.43
0.52
I
F
= 12A, T
J
= +125ºC
Leakage Current (Note 6)
I
R
- 0.05
0.3
mA
V
R
= 45V, T
J
= +25ºC
- 17 75
V
R
= 45V, T
J
= +125ºC
Typical Junction Capacitance
C
J
-
1000
- pF
4.0V,
1MHz
Notes:
5. Polymide PCB, 2oz. Copper, minimum recommended pad layout per
6. Short duration pulse test used to minimize self-heating effect.
