SBR is a registered trademark of Diodes Incorporated.
SBR10U300
Document number: DS30991 Rev. 9 - 2
2 of 5
www.diodes.com
June 2012
© Diodes Incorporated
SBR10U300CT
SBR10U300CTFP
Maximum Ratings
@T A = 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V RRM
V
RWM
V
RM
300 V
Average Rectified Output Current @T
C
= 150ºC I
O
10 A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
150 A
Peak Repetitive Reverse Surge Current (2 μS-1kHz) I
RRM
3 A
Isolation Voltage (ITO-220AB Only)
From terminal to heatsink t = 3 sec.
V
AC
2000 V
Thermal Characteristics
Characteristic Symbol Value Unit
Typical Thermal Resistance (per leg)
Package = TO-220AB
Package = ITO-220AB
R θJC 2
4 ºC/W
Operating and Storage Temperature Range T
J
, T
STG
-65 to +175 ºC
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Min Typ Max Unit Test Condition
Forward Voltage Drop V
F
-
-
0.64
-
0.86
0.71
0.92
V
I
F
= 5A, T
J
= 25ºC
I
F
= 5A, T
J
= 125ºC
I F = 10A, T J = 25ºC
Leakage Current (Note 6) I
R
- -
0.2
25
mA
V
R
= 300V, T
J
= 25ºC
V
R
= 300V, T
J
= 125ºC
Reverse Recovery Time t
rr
- 25 30
ns
I
F
= 0.5A, I
R
= 1A, I
RR
= 0.25A
- 28 35
I F = 1A, V R = 30V
di/dt = 100A/
μs, T
J
= 25ºC
Notes: 6. Short duration pulse test used to minimize self-heating effect.
7. Using heatsink (by Black Aluminum 45mm * 20mm * 12mm).
