SBR07U20LPS
0.7A SBR
®
SURFACE MOUNT SUPER BARRIER RECTIFIER
SBR07U20LPS
Document number: DS31358 Rev. 2 - 2
1 of 3
www.diodes.com
January 2008
© Diodes Incorporated
NEW PRODUCT
SBR is a re
Features
•
Ultra Low Forward Voltage Drop
•
Superior Reverse Avalanche Capability
•
Patented Super Barrier Rectifier Technology
•
Soft, Fast Switching Capability
•
150ºC Operating Junction Temperature
•
Lead Free by Design, RoHS Compliant (Note 1)
•
“Green” Device (Note 2)
Mechanical Data
•
Case: DFN1006H4-2
•
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020C
•
Terminal Connections: Cathode Dot
•
Terminals: Finish - NiPdAu over Copper leadframe. Solderable
per MIL-STD-202, Method 208
•
Marking Information: See Page 2
•
Ordering Information: See Page 2
•
Weight: 0.001 grams (approximate)
Bottom View
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
20
V
RMS Reverse Voltage
V
R(RMS)
14
V
Average Rectified Output Current (See Figure 1)
I
O
700
mA
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
7 A
Thermal Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Value
Unit
Maximum Thermal Resistance (Note 3)
R
θJA
224 ºC/W
Operating and Storage Temperature Range
T
j
, T
STG
-65 to +150
ºC
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit Test
Condition
Reverse Breakdown Voltage (Note 4)
V
(BR)R
20 - - V
I
R
= 50µA
Forward Voltage Drop
V
F
-
0.34
0.46
0.51
0.48
0.38
0.50
0.55
0.51
V
I
F
= 0.1A, T
j
= 25ºC
I
F
= 0.5A, T
j
= 25ºC
I
F
= 0.7A, T
j
= 25ºC
I
F
= 0.7A, T
j
= 125ºC
Leakage Current (Note 4)
I
R
-
6
1.5
50
5
µA
mA
V
R
= 20V, T
j
= 25ºC
V
R
= 20V, T
j
= 150ºC
Notes:
1. No purposefully added lead.
2. Diodes Inc.’s “Green” policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
3. Device mounted on FR-4 substrate. 2” x 2” 2oz. Copper, single sided PCB board.
4. Short duration pulse test used to minimize self-heating effect.
gistered trademark of Diodes Incorporated.
