SBR1045SD1
Document number: DS31351 Rev. 5 - 2
3 of 4
www.diodes.com
September 2011
© Diodes Incorporated
SBR1045SD1
NEW PROD
UC
T
SBR is a registered trademark of Diodes Incorporated.
10
100
1,000
10,000
0 5 10 15 20 25 30 35 40 45 50
V , REVERSE VOLTAGE(V)
R
Fig 3. Typical Total Capacitance
C
,
T
O
T
AL
C
A
P
A
C
IT
A
N
C
E (
p
F
)
T
f = 1MHz
Package Outline Dimensions
DO-201AD
Dim Min Max
A 25.40 ⎯
B 7.20 9.50
C 1.20 1.30
D 4.80 5.30
All Dimensions in mm
