Diodes SBR1060CTFP - Manual (Page 2)

SBR is a registered trademark of Diodes Incorporated.
SBR1060
Document number: DS30960 Rev. 7 - 2
2 of 5
www.diodes.com
June 2012
© Diodes Incorporated
SBR1060CT
SBR1060CTFP
Maximum Ratings (Per Leg)
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V
RRM
V
RWM
V RM
60 V
Average Rectified Output Current Per Device (Per Leg)
(Total)
I
O
5
10
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
120 A
Peak Repetitive Reverse Surge Current (2 μS-1kHz) I RRM
2 A
Isolation Voltage (ITO-220AB Only)
From terminal to heatsink t = 3 sec.
V
AC
2000 V
Thermal Characteristics (Per Leg)
Characteristic Symbol Value Unit
Typical Thermal Resistance
Package = TO-220AB
Package = ITO-220AB
R θJC 2
4 ºC/W
Operating and Storage Temperature Range T
J
, T
STG
-65 to +150 ºC
Electrical Characteristics (Per Leg)
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Min Typ Max Unit Test Condition
Forward Voltage Drop V
F
-
-
- 0.68
0.57
V
I
F
= 5A, T
J
= 25ºC
I
F
= 5A, T
J
= 125ºC
Leakage Current (Note 6) I R
- -
0.5
100
mA
V R = 60V, T J = 25ºC
V
R
= 60V, T
J
= 125ºC
Notes: 6. Short duration pulse test used to minimize self-heating effect.
Fig. 1 Forward Power Dissipation
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
0 2 4 6 8
I , AVERAGE FORWARD CURRENT (A)
F(AV)
P
,
P
O
WE
R
DI
SSI
P
A
T
IO
N
(W
)
D
0
Fig. 2 Typical Forward Characteristics
0.0001
0.001
0.01
0.1
1
10
100
0 300 600 900 1,200
V , INSTANTANEOUS FORWARD VOLTAGE (mV)
F
I
,
INST
ANT
A
NEOUS F
O
R
W
A
RD CURRE
NT
(
A
)
F
T = -55°C
A
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
