SBR10A45SP5
NEW PROD
UC
T
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V
RRM
V RWM
V
RM
45 V
Average Rectified Output Current I
O
10 A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I FSM
180 A
Thermal Characteristics
Characteristic Symbol Value Unit
Typical Thermal Resistance
Thermal Resistance Junction to Ambient (Note 5)
Thermal Resistance Junction to Ambient (Note 6)
R θJA
R θJA
102
60
ºC/W
Operating Temperature Range
V R
≤ 80% V
RRM
T
J
-65 to +150
ºC V
R
≤ 50% V
RRM
≤180
DC Forward Mode ≤200
Storage Temperature Range T STG
-65 to +175 ºC
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Reverse Breakdown Voltage (Note 7) V
(BR)R
45 - - V I
R
= 0.5mA
Forward Voltage Drop V
F
-
- 0.39
0.46 -
0.53
V
I
F
= 5A, T
J
= +25ºC
I
F
= 10A, T
J
= +25ºC
Leakage Current (Note 7) I
R
- - 400
μA
V
R
= 45V, T
J
= +25ºC
Notes: 5. FR-4 PCB, 2oz. Copper, minimum recommended pad layout per http://www.diodes.com.
6. Polymide PCB, 2oz. Copper, minimum recommended pad layout per http://www.diodes.com.
7. Short duration pulse test used to minimize self-heating effect.
