SBR is a registered trademark of Diodes Incorporated.
SBR10U150
Document number: DS30954 Rev.9 - 2
2 of 5
www.diodes.com
June 2012
© Diodes Incorporated
SBR10U150CT
SBR10U150CTFP
Maximum Ratings (Per Leg)
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V
RRM
V
RWM
V RM
150 V
Average Rectified Output Current Per Leg
Total
I
O
5
10
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
150 A
Peak Repetitive Reverse Surge Current (2 μS-1kHz) I RRM
3 A
Isolation Voltage (ITO-220AB Only)
From terminal to heatsink t = 3 sec.
V
AC
2000 V
Thermal Characteristics (Per Leg)
Characteristic Symbol Value Unit
Typical Thermal Resistance (per leg)
Package = TO-220AB
Package = ITO-220AB
R θJC 2
4 ºC/W
Operating and Storage Temperature Range T
J
, T
STG
-65 to +175 ºC
Electrical Characteristics (Per Leg)
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Min Typ Max Unit Test Condition
Forward Voltage Drop V
F
-
-
0.60
-
0.79
0.63
0.88
V
I F = 5A, T J = 25ºC
I
F
= 5A, T
J
= 125ºC
I
F
= 10A, T
J
= 25ºC
Leakage Current (Note 6) I
R
- -
0.2
25
mA
V
R
= 150V, T
J
= 25ºC
V
R
= 150V, T
J
= 125ºC
Notes: 6. Short duration pulse test used to minimize self-heating effect.
7. Using heatsink (by Black Aluminum (45mm * 20mm * 12mm)
