SBL3040CTP
Document number: DS31462 Rev. 6 - 2
2 of 4
April 2011
© Diodes Incorporated
SBL3040CTP
Maximum Ratings (Per Leg)
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
RM
40 V
Average Rectified Output Current
(Per Leg)
I
O
15
A
(Total)
30
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
230 A
Isolation Voltage
From Terminal Heatsink t = 1 min.
V
AC
2000 V
Thermal Characteristics (Per Leg)
Characteristic Symbol
Value
Unit
Typical Thermal Resistance Junction to Case
R
θJC
3
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
ºC
Electrical Characteristics (Per Leg)
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Forward Voltage Drop
V
F
- -
0.60
V
I
F
= 15A, T
J
= 25ºC
Leakage Current (Note 3)
I
R
- 0.15 1
mA
V
R
= 40V, T
J
= 25ºC
- - 75
V
R
= 40V, T
J
= 100ºC
Notes:
3. Short duration pulse test used to minimize self-heating effect.
0.01
0.1
1
10
100
0
200
400
600
800
Fig. 1 Typical Forward Characteristics
V , INSTANTANEOUS FORWARD VOLTAGE (mV)
F
I
, INS
T
A
NT
A
NEOU
S
F
O
RW
ARD
CURR
ENT
(
A
)
F
T = 25°C
A
T = -55°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
1
10
100
1,000
10,000
100,000
1,000,000
0
10
20
30
40
I,
I
N
S
T
AN
T
ANE
O
U
S
R
EV
E
R
SE
C
U
R
R
EN
T
(µ
A
)
R
Fig. 2 Typical Reverse Characteristics
V , INSTANTANEOUS REVERSE VOLTAGE (V)
R
T = 25°C
A
T = 85°C
A
T = 125°C
A
T = 150°C
A
