POWERDI is a registered trademark of Diodes Incorporated.

PDS5100H

Document number: DS30471 Rev. 24 - 2

2 of 5

www.diodes.com

March 2014

© Diodes Incorporated

PDS5100H



Maximum Ratings

(@T

A

= +25°C, unless otherwise specified.)

Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.

Characteristic Symbol

Value

Unit

Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage

V

RRM

V

RWM

V

R

100 V

RMS Reverse Voltage

V

R(RMS)

71 V

Average Rectified Output Current

I

O

5 A

Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave Superimposed on Rated Load

I

FSM

250 A




Thermal Characteristics

Characteristic Symbol

Typ

Max

Unit

Typical Power Dissipation (Note 9)

P

D

2.5

W

Thermal Resistance Junction to Case (Note 11)

R

θJC

5 °C/W

Thermal Resistance Junction to Soldering Point

R

θJS

2.0 °C/W

Thermal Resistance Junction to Ambient Air (Note 7) T

A

= +25°C

R

θJA

85

°C/W

Thermal Resistance Junction to Ambient Air (Note 8) T

A

= +25°C

R

θJA

70

°C/W

Thermal Resistance Junction to Ambient Air (Note 9) T

A

= +25°C

R

θJA

45

°C/W

Operating and Storage Temperature Range

T

J

, T

STG

-65 to +175

°C




Electrical Characteristics

(@T

A

= +25°C, unless otherwise specified.)

Characteristic Symbol

Min

Typ

Max

Unit

Test

Condition

Reverse Breakdown Voltage (Note 10)

V

(BR)R

100

V

I

R

= 3.5µA

Forward Voltage

V

F




0.67
0.55
0.75
0.62

0.71
0.58
0.80
0.66

V

I

F

= 5A, T

S

= +25°C

I

F

= 5A, T

S

= +125°C

I

F

= 10A, T

S

= +25°C

I

F

= 10A, T

S

= +125°C

Reverse Leakage Current (Note 10)

I

R



0.3
0.5

3.5
4.5

µA

mA

T

S

= +25°C, V

R

= 100V

T

S

= +125°C, V

R

= 100V

Notes:

7. FR-4 PCB, 2 oz. Copper, minimum recommended pad layout per http://www.diodes.com.
8. Polymide PCB, 2 oz. Copper, minimum recommended pad layout per http://www.diodes.com.
9. Polymide PCB, 2 oz. Copper. Cathode pad dimensions 9.4mm x 7.2mm. Anode pad dimensions 2.7mm x 1.6mm.

10. Short duration pulse test used to minimize self-heating effect.
11. Device mounted on Polymide 10cm x 10cm copper PC board,
