PDS560
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
60 V
RMS Reverse Voltage
V
R(RMS)
42 V
Average Rectified Output Current (See figure 4)
I
O
5 A
Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave Superimposed on Rated Load
I
FSM
150 A
Thermal Characteristics
Characteristic Symbol
Typ
Max
Unit
Thermal Resistance Junction to Soldering Point
R
θJS
⎯
2.0
°C/W
Thermal Resistance Junction to Ambient Air (Note 5) T
A
= +25°C
R
θJA
95
⎯
°C/W
Thermal Resistance Junction to Ambient Air (Note 6) T
A
= +25°C
R
θJA
70
⎯
°C/W
Thermal Resistance Junction to Ambient Air (Note 7) T
A
= +25°C
R
θJA
50
⎯
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Reverse Breakdown Voltage (Note 8)
V
(BR)R
60
⎯
⎯
V
I
R
= 0.2mA
Forward Voltage
V
F
⎯
⎯
⎯
⎯
0.61
0.54
0.71
⎯
0.67
0.60
0.77
0.68
V
I
F
= 5A, T
S
= +25
°C
I
F
= 5A, T
S
= +125
°C
I
F
= 8A, T
S
= +25
°C
I
F
= 8A, T
S
= +125
°C
Reverse Leakage Current (Note 8)
I
R
⎯
⎯
⎯
4
⎯
2
150
15
30
μA
mA
mA
T
S
= +25
°C, V
R
= 60V
T
S
= +100
°C, V
R
= 60V
T
S
= +125
°C, V
R
= 60V
Notes:
5. FR-4 PCB, 2 oz. Copper, minimum recommended pad lay
6. Polymide PCB, 2 oz. Copper, minimum recommended pad layout pe
7. Polymide PCB, 2 oz. Copper. Cathode pad dimensions 9.4mm x 7.2mm. Anode pad dimensions 2.7mm x 1.6mm.
8. Short duration pulse test used to minimize self-heating effect.
